Detectors
● High-Sensitivity Signal Detection
● Wideband Coverage
● Low Noise Floor Design
● Fast Response Time
● Temperature-Stable Performance
● Compact and Integration-Friendly Structure
| Part No. | Item | Frequency range | Main specification | Connector type | Material | Size(mm) | Download |
|---|---|---|---|---|---|---|---|
| MX-PD-0043-P | Detectors | 0.1-43GHz | Positive voltage，Sensitivity-20dBm,600V/W | 2.92mm Female-SMA Female | Gold-plated brass | 15x12.5x10 | |
| MX-PD-0050-P | Detectors | 0.1-50GHz | Positive voltage，Sensitivity-20dBm,600V/W | 2.4mm Female-SMA Female | Gold-plated brass | 15x12.5x10 | |
| MX-PD-0067-P | Detectors | 0.1-67GHz | Positive voltage，Sensitivity-20dBm,600V/W | 1.85mm Female-SMA Female | Gold-plated brass | 15x12.5x10 | |
| MX-PD-00110-P | Detectors | 0.1-110GHz | Positive voltage，Sensitivity-20dBm,600V/W | 1.0mm Female-SMA Female | Gold-plated brass | 15x12.5x10 | |
| MX-PD-0018-N | Detectors | 0.01-18GHz | Negative voltage，Sensitivity-40dBm,400V/W | SM male-SMA Female | Nickel-plated stainless steel | Coaxial length 35 | |
| MX-PD-0043-N | Detectors | 0.01-43GHz | Negative voltage，Sensitivity-40dBm,400V/W | 2.92mm male-SMA Female | Nickel-plated stainless steel | Coaxial length 35 | |
| MX-PD-2044-P | Detectors | 20-40GHz | Positive voltage, Sensitivity-20dBm,3000V/W | 2.92mm Female(Male is optional) | / | / | Download |
-
-
