Power Amplifiers
● High Output Power Density
● Wideband High Efficiency
● Excellent Linearity Performance
● Stable Temperature Adaptability
● Multi-Protection Mechanism Integration
● Compatible with Multiple Modulation Schemes
| Part No. | Item | Frequency range | Main Specification | Connector Type | Material | Size(mm) | Driver | Datasheet |
|---|---|---|---|---|---|---|---|---|
| MX-PA-0206-4442 | Power Amplifiers | 2-6GHz | PowerGain=44dB,Psat=42dBm | SMA Female | Aluminum alloy | 60x112x20mm | VD=+30V/4500mA | |
| MX-PA-0012-2530 | Power Amplifiers | 0.1-12GHz | Gain=25dB,P1=29dBm,Psat=30dBm | SMA Female | Gold-plated brass | 44x52x13mm | VD=+16V/400mA | |
| MX-PA-0118-2327 | Power Amplifiers | 1-18GHz | Gain=23dB,P1=26dBm,Psat=27dBm | SMA Female | Gold-plated brass | 44x52x13mm | VD=+12V/440mA | |
| MX-PA-0118-4027 | Power Amplifiers | 1-18GHz | Gain=40dB,P1=26dBm,Psat=27dBm | SMA Female | Gold-plated brass | 44x52x13mm | VD=+12V/550mA | |
| MX-PA-0218-3333 | Power Amplifiers | 2-18GHz | PowerGain=33dB,Psat=33dBm | SMA Female | Aluminum alloy | 60x112x20mm | VD=+30V/800mA | |
| MX-PA-0218-3334 | Power Amplifiers | 2-18GHz | PowerGain=33dB,Psat=34dBm | SMA Female | Aluminum alloy | 60x112x20mm | VD=+28V/1600mA | |
| MX-PA-0218-3939 | Power Amplifiers | 2-18GHz | PowerGain=439dB,Psat=39dBm | SMA Female | Aluminum alloy | 60x112x20mm | VD=+30V/2500mA | |
| MX-PA-0218-4039 | Power Amplifiers | 2-18GHz | PowerGain=40dB,Psat=39dBm | SMA Female | Aluminum alloy | 60x112x20mm | VD=+30V/2600mA | |
| MX-PA-0218-4042 | Power Amplifiers | 2-18GHz | PowerGain=40dB,Psat=42dBm | SMA Female | Aluminum alloy | 60x112x20mm | VD=+42V/3500mA | |
| MX-PA-0618-3543 | Power Amplifiers | 6-18GHz | PowerGain=35dB,Psat=43dBm | SMA Female | Aluminum alloy | 60x112x20mm | VD=+30V/3500mA | |
| MX-PA-0618-4130 | Power Amplifiers | 6-18GHz | Gain=41dB,P1=29dBm,Psat=30dBm | SMA Female | Gold-plated brass | 44x52x13mm | VD=+8V/520mA | |
| MX-PA-0020-2531 | Power Amplifiers | 0.1-20GHz | Gain=25dB,P1=29dBm,Psat=30dBm | SMA Female | Gold-plated brass | 44x52x13mm | VD=+16V/600mA | |
| MX-PA-2634-4032 | Power Amplifiers | 26-34GHz | Gain=25dB,P1=31dBm,Psat=32dBm | 2.92mm Female | Gold-plated brass | 44x52x13mm | VD=+8V/1400mA | |
| MX-PA-1840-4029 | Power Amplifiers | 18-40GHz | Gain=40dB,P1=28dBm,Psat=29dBm | 2.92mm Female | Gold-plated brass | 44x52x13mm | VD=+8V/1300mA | |
| MX-PA-1840-3431 | Power Amplifiers | 18-40GHz | Gain=40dB,P1=30dBm,Psat=31dBm | 2.92mm Female | Gold-plated brass | 45x75x13mm | VD=+12V/1200mA | |
| MX-PA-1840-3335 | Power Amplifiers | 18-40GHz | PowerGain=33dB,Psat=36dBm | 2.92mm Female | Gold-plated brass | 45x75x13mm | VD=+24V/2200mA | |
| MX-PA-4067-3518 | Power Amplifiers | 40-67GHz | Gain=25dB,P1=19dBm,Psat=18dBm | 1.85mm Female | Gold-plated brass | 44x52x13mm | VD=5V/550mA | |
| MX-PA-4060-2520 | Power Amplifiers | 40-60GHz | Gain=25dB,P1=19dBm,Psat=20dBm | 1.85mm Female | Gold-plated brass | 44x52x13mm | VD=5V/450mA | |
| MX-PA-4065-3630 | Power Amplifiers | 40-65GHz | PowerGain=36dB,Psat=30dBm | 1.85mm Female | Gold-plated brass | 60x112x20mm | VD=+16V/2000mA | |
| MX-PA-4067-0933 | Power Amplifiers | 40-67GHz | PowerGain=9dB,Psat=33dBm | 1.85mm Female | Gold-plated brass | 44x52x13mm | VD=+24V/26000mA | |
| MX-PA-4067-3233 | Power Amplifiers | 40-67GHz | PowerGain=32dB,Psat=33dBm | 1.85mm Female | Gold-plated brass | 60x112x20mm | VD=+24V/3000mA | |
| MX-PA-5763-3032 | Power Amplifiers | 57-63GHz | PowerGain=30dB,Psat=32dBm | WR-15 | Gold-plated brass | 50x100x22mm | VD=+20V/900mA | |
| MX-PA-0003-3230 | Power Amplifiers | 0.00001-3GHz | Gain=32dB,P1=30dBm,Psat=30.5dBm | SMA Female | Aluminum Alloy | 50×55×14mm | VD=+25V/550mA | Download |
| MX-PA-0006-1726 | Power Amplifiers | 0.001-6GHz | Gain=17dB,P1=26dBm,Psat=27dBm | SMA Female | Aluminum Alloy | 50×55×14mm | VD=+12V/520mA | Download |
| MX-PA-0006-3530 | Power Amplifiers | 0.01-6GHz | Gain=35dB,P1=30dBm,Psat=31dBm | SMA Female | Aluminum Alloy | 50×55×14mm | VD=+24V/350mA | Download |
| MX-PA-0006-3731 | Power Amplifiers | 0.8-6GHz | Gain=37dB,P1=31dBm,Psat=32dBm | SMA Female | Aluminum Alloy | 50×55×14mm | VD=+24V/550mA | Download |
| MX-PA-0012-3530 | Power Amplifiers | 0.1-12GHz | Gain=35dB,P1=29.5dBm,Psat=30dBm | SMA Female | Aluminum Alloy | 50×55×14mm | VD=+24V/550mA | Download |
| MX-PA-0018-2229 | Power Amplifiers | 0.000009-18GHz | Gain=22dB,P1=29dBm,Psat=30dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+24V/850mA | Download |
| MX-PA-0020-2529 | Power Amplifiers | 0.1-12GHz | Gain=25dB,P1=29dBm,Psat=30dBm | SMA Female | Gold-plated brass | 44×52×13mm | VD=+16V/550mA | Download |
| MX-PA-0118-3527 | Power Amplifiers | 1-18GHz | Gain=35dB,P1=27dBm,Psat=28.5dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+24V/750mA | Download |
| MX-PA-0118-3529 | Power Amplifiers | 1-18GHz | Gain=35dB,P1=29dBm,Psat=31dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+24V/750mA | Download |
| MX-PA-0208-2530 | Power Amplifiers | 2-18GHz | Gain=25dB,P1=29.5dBm,Psat=30.5dBm | SMA Female | Aluminum Alloy | 50×55×14mm | VD=+24V/550mA | Download |
| MX-PA-0218-3330 | Power Amplifiers | 2-18GHz | Gain=33dB,P1=30dBm,Psat=31dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+24V/600mA | Download |
| MX-PA-0218-3829 | Power Amplifiers | 2-18GHz | Gain=38dB,P1=29dBm,Psat=30dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+24V/850mA | Download |
| MX-PA-0618-2726 | Power Amplifiers | 6-18GHz | Gain=27dB,P1=26dBm,Psat=27dBm | SMA Female | Aluminum Alloy | 50×55×14mm | VD=+12V/500mA | Download |
| MX-PA-0618-3734 | Power Amplifiers | 6-18GHz | Gain=37dB,P1=34dBm,Psat=35dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+24V/900mA | Download |
| MX-PA-0618-3829 | Power Amplifiers | 6-18GHz | Gain=38dB,P1=29dBm,Psat=30dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+12V/750mA | Download |
| MX-PA-0618-4234 | Power Amplifiers | 6-18GHz | Gain=42dB,P1=34dBm,Psat=35dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+24V/950mA | Download |
| MX-PA-1218-4234 | Power Amplifiers | 12-18GHz | Gain=42dB,P1=34dBm,Psat=35dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+24V/950mA | Download |
| MX-PA-1230-3024 | Power Amplifiers | 12-30GHz | Gain=30dB,P1=24dBm,Psat=25dBm | 2.92mm Female | Aluminum Alloy | 50×55×14mm | VD=+12V/550mA | Download |
| MX-PA-1618-1625 | Power Amplifiers | 16-18GHz | Gain=16dB,P1=25dBm,Psat=26dBm | SMA Female | Aluminum Alloy | 50×55×14mm | VD=+12V/240mA | Download |
| MX-PA-1618-2532 | Power Amplifiers | 16-18GHz | Gain=25dB,P1=32dBm,Psat=34dBm | SMA Female | Aluminum Alloy | 50×65×14mm | VD=+24V/750mA | Download |
| MX-PA-1826-2131 | Power Amplifiers | 18-26.5GHz | Gain=21dB,P1=31dBm,Psat=32dBm | 2.92mm Female | Aluminum Alloy | 50×65×14mm | VD=+24V/800mA | Download |
| MX-PA-1840-2229 | Power Amplifiers | 18-40GHz | Gain=22dB,P1=29dBm,Psat=30dBm | 2.92mm Female | Aluminum Alloy | 50×65×14mm | VD=+24V/700mA | Download |
| MX-PA-1840-2623 | Power Amplifiers | 18-40GHz | Gain=26dB,P1=23.5dBm,Psat=24dBm | 2.92mm Female | Aluminum Alloy | 50×55×14mm | VD=+6V/380mA | Download |
| MX-PA-1840-3331 | Power Amplifiers | 18-40GHz | Gain=33dB,P1=31dBm,Psat=33dBm | 2.92mm Female | Aluminum Alloy | 50×65×14mm | VD=+24V/900mA | Download |
| MX-PA-1840-3527 | Power Amplifiers | 18-40GHz | Gain=35dB,P1=27dBm,Psat=28dBm | 2.92mm Female | Aluminum Alloy | 50×65×14mm | VD=+12V/700mA | Download |
| MX-PA-1840-3529 | Power Amplifiers | 18-40GHz | Gain=35dB,P1=29dBm,Psat=30dBm | 2.92mm Female | Aluminum Alloy | 50×65×14mm | VD=+12V/700mA | Download |
| MX-PA-1840-3829 | Power Amplifiers | 18-40GHz | Gain=38dB,P1=29dBm,Psat=30dBm | 2.92mm Female | Aluminum Alloy | 50×65×14mm | VD=+12V/700mA | Download |
| MX-PA-2633-3530 | Power Amplifiers | 26-33GHz | Gain=35dB,P1=30dBm,Psat=30.5dBm | 2.92mm Female | Aluminum Alloy | 50×65×14mm | VD=+24V/200mA | Download |
| MX-PA-2633-3532 | Power Amplifiers | 26-33GHz | Gain=35dB,P1=32dBm,Psat=32.5dBm | 2.92mm Female | Aluminum Alloy | 50×65×14mm | VD=+24V/400mA | Download |
| MX-PA-2634-4031 | Power Amplifiers | 26-34GHz | Gain=40dB,P1=31dBm,Psat=32dBm | 2.92mm Female | Aluminum Alloy | 50×55×14mm | VD=+24V/400mA | Download |
| MX-PA-2831-2823 | Power Amplifiers | 28-31GHz | Gain=28dB,P1=23dBm,Psat=24dBm | 2.92mm Female | Gold-plated brass | 44×36×12mm | VD=+6V/480mA | Download |
| MX-PA-3841-1925 | Power Amplifiers | 38-41GHz | Gain=19dB,P1=25dBm,Psat=26dBm | 2.92mm Female | Gold-plated brass | 44×36×12mm | VD=+6V/320mA | Download |
| MX-PA-4067-4032 | Power Amplifiers | 40-67GHz | Gain=40dB,P1=33dBm,Psat=32dBm | 1.85mm Female | Gold-plated brass | 80×50×13mm | VD=+24V/1000mA | Download |
-
-
