DC Blockers
● Wideband Coverage
● High Power-Capacity Design
● Low Insertion Loss
● Superior Temperature Stability
● Compact and Durable Design
● High Reliability & Long Service Life
| Part No. | Item | Frequency range | Main specification | Connector type | Material | Size(mm) |
|---|---|---|---|---|---|---|
| MX-DC-200k110G-30V | DC Blocks | 300kHz-110GHz | Insert loss2.5dB,Voltage30V，Power1W | 1.0mm Female-1.0mm Female or male | Gold-plated brass | 4x5x12 |
| MX-DC-300k110G-10V | DC Blocks | 300kHz-110GHz | Insert loss2.2dB,Voltage10V，Power1W | 1.0mm Female-1.0mm Female or male | Gold-plated brass | 4x5x12 |
| MX-DC-100k67GHz-25V | DC Blocks | 100kHz-67GHz | Insert loss1.5dB，Voltage25V，Power1W | 1.85mm Female-1.85mm Female or male | Gold-plated brass | 4x5x12 |
| MX-DC-10M67GHz-50V | DC Blocks | 10MHz-67GHz | Insert loss1.5dB，Voltage50V，Power5W | 1.85mm Female-1.85mm Female or male | Gold-plated brass | 4x5x12 |
| MX-DC-100M67GHz-50V | DC Blocks | 100MHz-67GHz | Insert loss1dB，Voltage50V，Power5W | 1.85mm Female-1.85mm Female or male | Gold-plated brass | 4x5x12 |
| MX-DC-30k50G-25V | DC Blocks | 30kHz-50GHz | Insert loss1dB，Voltage25V，Power1W | 2.92mm Female-2.92mm Female or male | Gold-plated brass | 4x5x12 |
| MX-DC-100k50G-25V | DC Blocks | 50kHz-50GHz | Insert loss1dB，Voltage25V，Power1W | 2.92mm Female-2.92mm Female or male | Gold-plated brass | 4x5x12 |
| MX-DC-10M50G-50V | DC Blocks | 10MHz-50GHz | Insert loss1dB，Voltage50V，Power5W | 2.92mm Female-2.92mm Female or male | Gold-plated brass | 4x5x12 |
-
-
