Microwave Limiters
● High Power-Capacity Protection
● Fast Response Time
● Low Insertion Loss Design
● Wideband Operating Range
● Superior Temperature Stability
● Miniaturized Integrated Packaging
| Part No. | Item | Frequency range | Main specification | Connector type | Material | Size(mm) |
|---|---|---|---|---|---|---|
| MX-LM-0006-17 | Amplitude limiter | DC-6GHz | Insert loss0.5dB,Limiting amplitude17dBm，Power max2W | SMA Female-SMA male | Gold-plated brass | 15x12.5x10 |
| MX-LM-0812-14 | Amplitude limiter | 8-12GHz | Insert loss0.6dB,Limiting amplitude14dBm，Power max20W | SMA Female-SMA male | Gold-plated brass | 15x12.5x10 |
| MX-LM-0018-18 | Amplitude limiter | DC-18GHz | Insert loss0.5dB,Limiting amplitude18dBm，Power max2W | SMA Female-SMA male | Gold-plated brass | 15x12.5x10 |
| MX-LM-0618-18 | Amplitude limiter | 6-18GHz | Insert loss0.8dB,Limiting amplitude18dBm，Power max10W | SMA Female-SMA male | Gold-plated brass | 15x12.5x10 |
| MX-LM-0020-14 | Amplitude limiter | DC-20GHz | Insert loss1dB,Limiting amplitude14dBm，Power max5W | SMA Female-SMA male | Gold-plated brass | 15x12.5x10 |
| MX-LM-1540-17 | Amplitude limiter | 15-40GHz | Insert loss1.5dB,Limiting amplitude17dBm，Power max1W | 2.92mm Female-2.92mm male | Gold-plated brass | 15x12.5x10 |
-
-
