Coaxial Loads/ Coaxial Terminations

● High reliability and good repeatability.

● Max power:100.

● Customrized support.

Coaxial Loads/ Coaxial Terminations img
Manual catalog Coaxial load selection
Frequency range (GHz)VSWRConnectorBearing power (W)
DC-2GHz 1.1 SMA/N 2W
DC-4GHz 1.1 SMA/N 2W
DC-8GHz 1.15 SMA/N 2W
DC-12GHz 1.25 SMA/N 2W
DC-18GHz 1.3 SMA/N 2W
DC-26.5GHz 1.3 SMA/3.5MM 2W
DC-40GHz 1.35 2.92mm/ 2.4mm 2W
DC-50GHz 1.4 2.4mm 2W
DC-67GHz 1.45 1.85mm 2W
DC-2GHz 1.1 SMA/N/TNC/BNC/7-16 5W
DC-4GHz 1.1 SMA/N/TNC/BNC/7-16 5W
DC-8GHz 1.15 SMA/N 5W
DC-12GHz 1.25 SMA/N 5W
DC-18GHz 1.3 SMA/N 5W
DC-26.5GHz 1.3 SMA/3.5mm 5W
DC-40GHz 1.35 2.92mm/ 2.4mm 5W
DC-50GHz 1.4 2.4mm 5W
DC-67GHz 1.45 1.85mm 5W
DC-2GHz 1.1 SMA/N/TNC/BNC/7-16/4.3-10 10W
DC-4GHz 1.2 SMA/N/TNC/BNC/7-16/4.3-10 10W
DC-8GHz 1.25 SMA/N 10W
DC-12GHz 1.25 SMA/N 10W
DC-18GHz 1.3 SMA/N 10W
DC-26.5GHz 1.3 SMA/3.5mm 10W
DC-40GHz 1.35 2.92mm 10W
DC-50GHz 1.4 2.4mm 10W
DC-67GHz 1.45 1.85mm 10W
DC-2GHz 1.1 SMA/N/TNC/BNC/7-16/4.3-10 25W
DC-4GHz 1.2 SMA/N/TNC/BNC/7-16/4.3-10 25W
DC-8GHz 1.25 SMA/N 25W
DC-12GHz 1.25 SMA/N 25W
DC-18GHz 1.3 SMA/N 25W
DC-26.5GHz 1.3 SMA/3.5mm 25W
DC-40GHz 1.35 2.92mm 25W
DC-2GHz 1.1 SMA/N/TNC/BNC/7-16/4.3-10 50W
DC-4GHz 1.2 SMA/N/TNC/BNC/7-16/4.3-10 50W
DC-8GHz 1.25 SMA/N 50W
DC-12GHz 1.25 SMA/N 50W
DC-18GHz 1.3 SMA/N 50W
DC-26.5GHz 1.3 SMA/3.5mm 50W
DC-40GHz 1.35 2.92mm 50W
DC-2GHz 1.1 SMA/N/TNC/7-16/4.3-10 100W
DC-4GHz 1.2 SMA/N/TNC/7-16/4.3-10 100W
DC-8GHz 1.25 SMA/N/7-16 100W
DC-12GHz 1.3 SMA/N 100W
DC-18GHz 1.35 SMA/N 100W
